Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Alternate Mfr Part Number | M4281422 |
| Body Style | Cylindrical |
| Current Consumption | 400 mA AC (Max.), 300 mA DC (Max.) |
| Current, Switching | 400/300 mA |
| Dimensions | 3.228" L |
| Frequency, Switching | 0.06 kHz |
| Housing Material | Brass |
| IP Rating | IP67 |
| Maximum Operating Temperature | 70 C |
| Measurement Range | 12 mm |
| Minimum Operating Temperature | -25 C |
| Mounting Type | M18 Threaded |
| Operating Temperature, Maximum | 70 C |
| Operating Temperature, Minimum | -25 C |
| Output | NO |
| Primary Type | Inductive Proximity Sensors |
| Series | |
| Supply Voltage | 20-250 VAC ; 10-300 VDC |
| Termination | M12, 2 Pin |
Overview
Features:
