Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Alternate Mfr Part Number | NI40U-CP40-AP6X2 |
| Body Style | Rectangular |
| Depth | 0.079" (2mm) |
| Dimensions | 114 x 40 x 40 mm |
| Housing Material | Plastic |
| IP Rating | IP68 |
| Length | 4.488" (114mm) |
| Maximum Operating Temperature | 85 C |
| Measurement Range | 40 mm |
| Minimum Operating Temperature | -30 C |
| Mounting Type | Non-Flush |
| Operating Temperature, Maximum | 85 C |
| Operating Temperature, Minimum | -30 C |
| Output | PNP |
| Primary Type | Inductive Proximity Sensors |
| Shielding | Unshielded |
| Shop By | Factory Choice |
| Supply Voltage | 10-30 VDC |
| UPC Code | 5056070959934 |
Overview
RS Pro Proximity Limit
Adjustable sensing head, 9 positions
Fixed terminal base for quick sensor replacement
Connection via terminal compartment
RS Pro Proximity Inductive Sensor
Extended sensing ranges
Sense all metals at the same distance - with no reduction factor
IP67 Rating (Barrel is IP68)
Yellow LED output status display. Rectangular, Large Block, Stubby Cube and Combiprox also have a green LED for power on, flashing indicates a short circuit
High switching frequency
3 wire dc
No load current 15mA max.
Inherent weld field immunity
